MECO Omaha AM10 Single-Sided Cantilever Rack Add-On Kit — 10' Tall, 36" Arms, 400 lb per Arm
Who it's for: Anyone with a MECO SM10 starter unit who wants to extend the row. The AM10 adds one more bay of 10' single-sided storage using a single shared upright, for lumber, bundled pipe, tubing and other long loads that need deeper arms.
Best for: extending an existing SM10 row one bay at a time at a lower cost per bay than another starter.
Not the best fit for: a first bay. An add-on needs a starter unit to attach to, so start with the SM10.
Need a starter unit first? View the matching SM10 Single-Sided Cantilever Rack Starter Kit →
The AM10 is the Series 1000 Medium Duty add-on kit designed to extend your SM10 starter unit into a continuous row system. Where a starter unit requires 2 uprights to form a single bay, each add-on unit adds a full bay using only 1 shared upright — eliminating redundant framing, reducing cost per bay, and maximizing your floor footprint.
Ships complete with 1 upright, 6 straight arms, and a brace set — everything needed to attach directly to an existing SM10 bay. Arms adjust on 3" centers the full height of the upright.
What's Included
- 1 upright (10' height, 45" base length)
- 6 straight arms (36" length, 400 lb capacity each)
- 1 brace set (71")
- All hardware for assembly
Why expand with the AM10
Lower cost per bay than a second starter — Add-on units share one upright with the adjacent bay instead of requiring two. You get the same storage bay at a fraction of the full starter price.
Same arm capacity, same system — The AM10 uses identical Series 1000 arms and hardware as the SM10. No compatibility concerns, no mixed components — everything integrates directly.
Build as long as you need — Chain multiple AM10 units together to create a continuous row of any length. Each unit adds one full bay of storage at 10' tall with 36" arms.
Forklift accessible — Open base design allows loading and unloading directly from the aisle, same as the starter unit.
Not sure which rack you need? Read our cantilever rack buying guide for help with arm length, capacity, upright spacing and height.
Questions before ordering? Call (929) 577-4339 or email support@mywarehouseworld.com.
Floor Anchors (Required, Not Included): The add-on upright must be anchored to the floor before use. MECO recommends a minimum of 2 anchors per base — 1 in the front and 1 in the back on opposite sides of the base. Each base has holes for up to 4 anchors. Recommended anchor spec: ½" × 4¼". Anchors are not sold by MECO and can be bought locally or provided by us at additional cost. Building codes vary by location — consult local codes for specific requirements.
Series 1000 Medium Duty Single-sided Add-On Units — Model Comparison
| Model | Height | Arm Length | Arms Included | Arm Capacity | Unit Weight |
|---|---|---|---|---|---|
| AM6 | 6' | 12" | 3 | 1,000 lb | 133 lb |
| AM8 | 8' | 24" | 4 | 600 lb | 163 lb |
| AM10 (this model) | 10' | 36" | 6 | 400 lb | 256 lb |
Arm capacity is set by arm length. Upright capacity is lower on taller uprights and with longer arms, so check the upright rating for the height and arm length you choose. All capacities are per MECO Omaha specifications based on evenly distributed loads.
Need double-sided storage? See the AMD6, AMD8, AMD10 double-sided add-on units.
Specifications
| Specification | Detail |
|---|---|
| Series | Series 1000 Medium Duty |
| Unit Type | Add-On |
| Configuration | Single-sided |
| Upright Height | 10' |
| Base Length | 45" |
| Arm Length | 36" |
| Arm Capacity | 400 lb per arm (evenly distributed load) |
| Number of Arms | 6 |
| Brace Set | 71" |
| Unit Weight | 256 lb |
| Arm Adjustability | 3" centers |
| Standard Color | Gray |
| Compatible Starter | SM10 Single-Sided Cantilever Rack Starter Kit |
Important: Capacities are based on evenly distributed loads. Arms must never be placed on the back side of a single-sided upright. Unit must be anchored to the floor per assembly instructions. Add-on units must only be used with a compatible SM10 starter unit.
FAQ
What does the AM10 attach to?
The AM10 attaches to a MECO SM10 starter unit, or to another AM10, and shares one upright with the bay next to it. It must only be used with a compatible SM10 starter.
What comes with the AM10?
1 upright (10' height, 45" base length), 6 straight arms (36" long, 400 lb capacity each), a 71" brace set and all assembly hardware.
How much weight can each AM10 arm hold?
Each arm is rated for 400 lb with the load evenly distributed, per MECO Omaha's published ratings.
Do I need a starter unit before buying the AM10?
Yes. Every row begins with one SM10 starter unit, which has 2 uprights. Each AM10 then adds one bay using a single upright.
How many AM10 add-ons can I connect?
There is no set limit. Chain as many AM10 units as your space allows to build a continuous row.
Does the AM10 need to be anchored to the floor?
Yes. The add-on upright must be anchored before use, with at least 2 anchors per base. The recommended anchor is ½" × 4¼". Anchors are not included. You can buy them locally, or we can provide them at additional cost.
Can the arms be moved?
Yes. Arms adjust up and down on 3" centers, so you can set the spacing to fit your material.
Does it come assembled?
No. The AM10 ships as components with all the hardware needed to assemble it on site.
Can I get arm lips?
Yes. Bolt-on 2" arm lips are available for this model. Contact us to order with lips. Other options are listed on the Customization & Accessories tab.
How is the AM10 delivered?
It ships by freight truck from MECO Omaha in Omaha, NE, as curbside delivery. The unit weighs 256 lb, so have a forklift or pallet jack ready to unload, or ask us to add liftgate delivery to your freight quote. You can also use your own freight carrier at no extra cost.
Is My Warehouse World an authorized MECO Omaha dealer?
Yes. We're an authorized dealer for MECO Omaha, and every order is placed directly with MECO and ships from their facility.
Customization & Accessories
Arm Lips
Bolt-on 2" arm lips are available for this model. Lips extend 2" above the arm surface and retain cylindrical loads — pipe, tubing, round bar — that may otherwise roll off the end of the arm. Non-structural; a retention feature only.
To order with arm lips, contact us at support@mywarehouseworld.com or (929) 577-4339.
Additional Customization Options
Contact us to discuss any of the following configurations:
Inclined Arms — For cylindrical loads that tend to roll, inclined arms pitch at 20° (approximately 4.36" per foot) to keep material secure on the rack.
Bolt-On Pipe Sockets — Field-installable pipe sockets (1⅜" inside diameter) provide an additional stop at the end of the arm for round stock and tubing.
Drop-In Deck Support Saddles — Convert to a decked system for storing boxes, cartons, or furniture. Pre-engineered to accommodate 2×4 cross supports.
Custom Colors — Available at additional cost.
To discuss customization options, call (929) 577-4339 or email support@mywarehouseworld.com.
